EN AW-6082 · Structural aluminium alloy

Premium 50.8mm x 50.8mm x 9.53mm Aluminium Angle - Grade 6082 T6 for Structural Applications

50.8 × 50.8 × 9.53 mm (2″ × 2″ × 3/8″)1000 mm length

PhotoPremium 50.8mm x 50.8mm x 9.53mm Aluminium Angle - Grade 6082 T6 for Structural Applications 50.8 × 50.8 × 9.53 mm (2″ × 2″ × 3/8″) – photo 1 of 2
PhotoPremium 50.8mm x 50.8mm x 9.53mm Aluminium Angle - Grade 6082 T6 for Structural Applications 50.8 × 50.8 × 9.53 mm (2″ × 2″ × 3/8″) – photo 2 of 2
End profile

50.8 × 50.8 × 9.53 mm

  • Excellent corrosion resistance

£83.28incl. VATper 1000 mm length

Quantity 1 = one 1000 mm length.

LengthSupplied as one length
Finish

Item total £83.28 1 × £83.28 per 1000 mm length

Secure checkout: Card, Apple Pay, Google Pay or Shop Pay

Availability
Available to order
Delivery
UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
Returns
Return within 14 days of receipt. Returns policy
Overview

Overview

About this aluminium angle

Product Overview

This Premium Aluminium Angle is crafted from Grade 6082 T6 aluminium, a medium strength alloy known for its excellent corrosion resistance and durability. The mechanical properties of this alloy are enhanced through the addition of magnesium, manganese, and silicon, making it ideal for various structural applications.

Typical Uses

Common applications for this aluminium angle include:

  • Frame building
  • Automotive components & trims
  • Cranes
  • Trusses
  • Bridges

Dimensions & Specifications

Specification Measurement
Length 50.8mm
Width 50.8mm
Thickness 9.53mm

Technical Specifications

This aluminium angle is recognized as the highest strength grade in the 6000 series, making it suitable for demanding structural applications. Its properties include:

  • High corrosion resistance
  • Good machinability and weldability
  • Enhanced strength due to alloy composition

FAQ

Q: What is Grade 6082 T6 aluminium used for?

A: Grade 6082 T6 aluminium is commonly used for structural applications due to its high strength and corrosion resistance.

Q: Can this aluminium angle be welded?

A: Yes, it has good weldability, making it suitable for various fabrication processes.

Q: What are the dimensions of this aluminium angle?

A: The dimensions are 50.8mm x 50.8mm x 9.53mm (2" x 2" x 3/8").

Key features

  • Grade 6082 (EN AW-6082, structural aluminium alloy)
  • Excellent corrosion resistance
FAQs

FAQs

Before you order

What does one unit of this item supply?

Quantity 1 = one 1000 mm length.

Can you supply other sizes or a cutting list?

Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.

Specifications

Specifications

Product dimensions

Dimensions and supply details for this aluminium angle
Size50.8 × 50.8 × 9.53 mm (2″ × 2″ × 3/8″)
Supplied length1000 mm
FinishNot stated
Grade6082
SKUAWH_IS8355

Material properties

Material properties
Width50.8mm
Thickness9.53mm

Catalogue name Premium 50.8mm x 50.8mm x 9.53mm Aluminium Angle - Grade 6082 T6 for Structural Applications

Technical data (EN AW-6082)

Technical data · alloy

6082 / EN AW-6082

  • Si 0.7–1.3%Silicon
  • Mg 0.6–1.2%Magnesium
  • Mn 0.4–1.0%Manganese
Alloy
Structural aluminium alloy
Designation
EN AW-6082
Density
2.70 g/cm³

Typical composition for the grade, for guidance — not a mill certificate for this item.

Request a quote

Need several sizes, long runs or a cert?

Premium 50.8mm x 50.8mm x 9.53mm Aluminium Angle - Grade 6082 T6 for Structural Applications 50.8 × 50.8 × 9.53 mm (2″ × 2″ × 3/8″)1000 mm / Mill Finish£83.28 per 1000 mm length

Send us your cutting list or question. We reply with prices and availability for your full list.

Fields marked with an asterisk are required.

One line per item: quantity × size × cut length.
Example: 4 × 25.4 mm OD × 1.6 mm wall tube @ 600 mm
