CW614N · Free-machining brass
Premium 24mm Diameter Brass Round Bar - High-Performance CZ121 Alloy for Furniture and Architectural Applications
24 mm1000 mm length
24 mm
£209.40incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 24 mm.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this brass round bar
Product Overview
Our Premium Brass Round Bar is available in a grade CZ121, an alpha/beta alloy known for its exceptional hardness and tensile strength. The addition of lead in its composition significantly improves machinability, ensuring a smooth fabrication process. The lead remains insoluble in the microstructure of the brass, allowing soft particles to act as chip breakers, which enhances the overall performance during machining.
Applications
This versatile brass round bar has a wide array of applications, including:
- Furniture manufacturing
- Architectural extrusions
- Electrical components
- Locks and hinges
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Diameter | 24mm |
Technical Specifications
- Material: CZ121 Brass Alloy
- Type: Alpha/Beta Alloy
- Enhanced Machinability: Lead addition
- Hardness: High
- Tensile Strength: Excellent
FAQ
Q: What is the main advantage of using CZ121 brass?A: CZ121 brass is known for its hardness and tensile strength, making it ideal for various applications where durability is a priority.
Q: Can this brass round bar be used for electrical components?A: Yes, the brass round bar is suitable for use in electrical components due to its conductive properties.
Q: How does the addition of lead improve machinability?A: The lead in the brass alloy remains insoluble and helps break chips during machining, leading to a smoother cutting process.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 24 mm.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 24 mm |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | CZ121 |
| SKU | AWH_IS5712 |
Catalogue name Premium 24mm Diameter Brass Round Bar - High-Performance CZ121 Alloy for Furniture and Architectural Applications
Technical data (CW614N)
Technical data · alloy
CZ121 / CW614N
- Cu 57–59%Copper
- Pb 2.5–3.5%Lead
- Zn BalanceZinc
- Alloy
- Free-machining brass
- Designation
- CW614N
- Density
- 8.47 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
24 mm £209.40 per 1000 mm length
