CW614N · Free-machining brass
Premium 88.9mm Diameter Brass Round Bar - High-Performance CZ121 Alloy with Excellent Machinability for Various Applications
88.9 mm (3 1/2″)1000 mm length
88.9 mm
£4,974.19incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 88.9 mm (3 1/2″).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this brass round bar
Product Overview
This Premium Brass Round Bar is crafted from high-quality CZ121 grade, an alpha/beta alloy known for its exceptional hardness and tensile strength. The addition of lead in its composition significantly improves machinability, while the lead remains insoluble within the brass microstructure, allowing for effective chip breaking during machining processes.
With excellent hot working capabilities, this brass round bar is suitable for various applications, including:
- Furniture manufacturing
- Architectural extrusions
- Electrical components
- Locks and hinges
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Diameter | 88.9mm (3 1/2 inches) |
Technical Specifications
- Material: CZ121 Brass Alloy
- Type: Alpha/Beta Alloy
- Lead Addition: Improves Machinability
- Applications: Suitable for various industrial uses
FAQ
What is the hardness of CZ121 brass?
The CZ121 brass alloy is known for its high hardness and tensile strength, making it suitable for demanding applications.
Can this brass round bar be machined?
Yes, the lead addition in CZ121 significantly enhances its machinability, making it easier to work with.
What are common applications for brass round bars?
Common applications include furniture manufacturing, architectural extrusions, and various electrical components.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 88.9 mm (3 1/2″).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 88.9 mm (3 1/2″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | CZ121 |
| SKU | AWH_IS5694 |
Catalogue name Premium 88.9mm Diameter Brass Round Bar - High-Performance CZ121 Alloy with Excellent Machinability for Various Applications
Technical data (CW614N)
Technical data · alloy
CZ121 / CW614N
- Cu 57–59%Copper
- Pb 2.5–3.5%Lead
- Zn BalanceZinc
- Alloy
- Free-machining brass
- Designation
- CW614N
- Density
- 8.47 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
88.9 mm (3 1/2″) £4,974.19 per 1000 mm length
