Premium 40 Amp 30mA 1P+N 2Mod Type A RCBO with High-Performance Short-Circuit Capacity and Electro-Magnetic Design
£62.66incl. VATeach
Quantity 1 = one item as described.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this product
Overview
This Premium RCBO (Residual Current Breaker with Overcurrent) features a robust electro-magnetic design, making it suitable for various electrical applications. With a rated current of 40A and a residual current of 30mA, this device provides reliable protection against electrical faults and ensures safety in your installations.
Technical Specifications
- Type: Electro-magnetic type
- Residual Current Characteristics: A
- Pole Number: 1P+N
- Tripping Curve: C
- Rated Short-Circuit Capacity: 10kA
- Rated Current: 20/40A
- Rated Voltage: 240V AC
- Rated Frequency: 50/60Hz
- Rated Residual Operating Current: 30mA
- Tripping Duration: Instantaneous - 0.1s
- Electro-Mechanical Endurance: 4000 cycles
- Connection Terminal: Pillar terminal with clamp
- Connection Capacity: Rigid conductor 16mm
- Terminal Connection Height: 21.5mm
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Rated Current | 40A |
| Rated Voltage | 240V AC |
| Short-Circuit Capacity | 10kA |
| Tripping Duration | 0.1s |
| Electro-Mechanical Endurance | 4000 cycles |
FAQs
- What is the purpose of an RCBO? An RCBO is designed to protect against both earth faults and overcurrent, ensuring safety in electrical systems.
- How does the tripping duration affect performance? A shorter tripping duration, such as 0.1s, allows for quick disconnection in case of a fault, which enhances safety.
- Can this RCBO be used in residential applications? Yes, it is suitable for both residential and commercial installations, providing essential protection.
