1.4404 · Low-carbon molybdenum stainless steel
High-Performance 150mm x 12mm 316L Plain Finish Stainless Steel Flat Bar with Excellent Corrosion Resistance
150 × 12 mm1000 mm length
- Excellent corrosion resistance
£718.85incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this stainless steel flat bar
Product Overview
This high-performance stainless steel flat bar is made from austenitic grade 316L, known for its exceptional corrosion resistance, particularly in marine environments. The 316L grade is often referred to as 'marine grade' due to its ability to withstand the harsh conditions of both atmospheric and cold seawater corrosion. As one of the most weldable high-alloy steels available, it can be effectively welded using all fusion and resistance welding processes.
Applications
The 316L stainless steel flat bar is widely used in various industries and applications, including:
- Boat fixtures
- Offshore platforms
- Construction projects
- Chemical containers
- Transport systems
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 150mm |
| Width | 12mm |
| Material Grade | 316L |
Technical Specifications
- Corrosion Resistance: Excellent resistance to seawater and atmospheric conditions.
- Weldability: Suitable for all fusion and resistance welding processes.
- Grade: Austenitic 316L, also known as marine grade.
FAQs
What is the difference between 316 and 316L stainless steel?
316L stainless steel has a lower carbon content compared to 316, which enhances its corrosion resistance and makes it suitable for welding applications.
Can this flat bar be used in marine applications?
Yes, the 316L grade is specifically designed for marine environments due to its excellent resistance to corrosion from seawater.
What welding processes can be used with 316L stainless steel?
316L can be welded using all fusion and resistance welding processes, making it versatile for various applications.
Key features
- Grade 316L (1.4404, low-carbon molybdenum stainless steel)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 150 × 12 mm |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 316L |
| SKU | AWH_IS5566 |
Material properties
| Width | 12mm |
|---|---|
| Material Grade | 316L |
Catalogue name High-Performance 150mm x 12mm 316L Plain Finish Stainless Steel Flat Bar with Excellent Corrosion Resistance
Technical data (1.4404)
Technical data · alloy
316L / 1.4404
- Cr 16.5–18.5%Chromium
- Ni 10–13%Nickel
- Mo 2.0–2.5%Molybdenum
- Alloy
- Low-carbon molybdenum stainless steel
- Designation
- 1.4404
- Density
- 8.00 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
150 × 12 mm £718.85 per 1000 mm length
