EN AW-6082 · Structural aluminium alloy
Premium Structural Grade 6082 T6 Aluminium Flat Bar 76.2mm x 3.2mm for High-Stress Applications
76.2 × 3.2 mm (3″ × 1/8″)1000 mm length
- Excellent corrosion resistance
- Easy to machine
£28.26incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium flat bar
Product Overview
The Premium Structural Grade 6082 T6 Aluminium Flat Bar is the highest strength alloy in the 6000 Series. With the addition of magnesium, manganese, and silicon, this alloy enhances both mechanical and corrosion resistance properties while maintaining excellent machinability and weldability.
Applications
6082 T6 is particularly suited for highly stressed applications, including:
- Trusses
- Bridges
- Cranes
- Automotive components
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 76.2mm |
| Width | 3.2mm |
Technical Specifications
This high-performance aluminium flat bar is designed for durability and strength, ensuring optimal performance in demanding environments.
FAQ
- What is the alloy used in this flat bar? The flat bar is made from structural grade 6082 T6 aluminium.
- Can this aluminium flat bar be welded? Yes, it retains good weldability due to its composition.
- What are the corrosion resistance properties? The alloy is enhanced with magnesium and silicon, providing excellent corrosion resistance.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 76.2 × 3.2 mm (3″ × 1/8″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS1681 |
Material properties
| Width | 3.2mm |
|---|
Catalogue name Premium Structural Grade 6082 T6 Aluminium Flat Bar 76.2mm x 3.2mm for High-Stress Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
76.2 × 3.2 mm (3″ × 1/8″) £28.26 per 1000 mm length
