EN AW-6082 · Structural aluminium alloy
6082 Aluminium Angle
101.6 × 101.6 mm (4″ × 4″ × 1/2″)1000 mm length
101.6 × 101.6 mm
- Excellent corrosion resistance
£313.74incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium angle
This premium aluminium angle measures 101.6mm x 101.6mm and has a thickness of 12.7mm (1/2 inch). It is made from Grade 6082 T6 aluminium, which is known for its medium strength and excellent corrosion resistance. The mechanical properties of this alloy are enhanced with the addition of magnesium, manganese, and silicon, while maintaining good machinability and weldability. This material is highly recommended for structural applications due to its strength.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
Technical Specifications The high-performance aluminium angle boasts the following technical specifications:
Applications
Applications
Where this angle is used
The aluminium angle is versatile and can be used in various applications, including:
- Frame building
- Automotive components & trims
- Cranes
- Trusses
- Bridges
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 101.6 × 101.6 mm (4″ × 4″ × 1/2″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS6604 |
Material properties
| Width | 101.6mm |
|---|---|
| Thickness | 12.7mm (1/2 inch) |
Catalogue name High-Performance 101.6mm x 101.6mm Aluminium Angle - Grade 6082 T6 with Excellent Corrosion Resistance for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
101.6 × 101.6 mm (4″ × 4″ × 1/2″) £313.74 per 1000 mm length
