EN AW-6063 · Architectural aluminium alloy

25mm x 9mm x 3mm Aluminium Double Channel Mill Finish 6063 - Heavy Duty, Corrosion-Resistant, Ideal for Shelving & Mounting Brackets

25 × 9 × 3 mmMill Finish

5 reviews, rated 4.8 out of 5
Photo25mm x 9mm x 3mm Aluminium Double Channel Mill Finish 6063 - Heavy Duty, Corrosion-Resistant, Ideal for Shelving & Mounting Brackets 25 × 9 × 3 mm – photo 1 of 2
Photo25mm x 9mm x 3mm Aluminium Double Channel Mill Finish 6063 - Heavy Duty, Corrosion-Resistant, Ideal for Shelving & Mounting Brackets 25 × 9 × 3 mm – photo 2 of 2
End profile

25 × 9 × 3 mm

  • Excellent corrosion resistance
  • Fair weldability
  • Cut to the metres you order

£45.00incl. VATper metre

Quantity 1 = 1 metre. Up to 5 m comes as one piece; longer totals are supplied in pieces of up to 5 m.

Item total £45.00 1 × £45.00 per metre · ≈ 1.75 kg

Secure checkout: Card, Apple Pay, Google Pay or Shop Pay

Availability
Available to order
Delivery
UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
Returns
Return within 14 days of receipt. Returns policy
Cutting
Cut from stock to the metres you order. How cutting works
Overview

Overview

About this aluminium channel

This double-channel aluminum profile is commonly used in applications where dual mounting or structural support is required, such as in shelving systems, mounting brackets, or tracks for sliding doors. Its versatility, coupled with its excellent corrosion resistance and sturdy construction, makes it suitable for both indoor and outdoor use in construction, manufacturing, and DIY projects.

  • Material: Aluminium, known for its lightweight properties and excellent corrosion resistance.
  • Weldability: Fair weldability, suggesting it can be welded with moderate ease.
  • Shape: Double channel-shaped, providing two parallel channels within the profile, suitable for unique structural and mounting requirements.
  • Corrosion Resistance: Excellent, making it suitable for use in environments prone to moisture or other corrosive elements.
  • Finish: Mill Finish, indicating a smooth surface finish typical of aluminum products straight from the manufacturing process.
  • Grade: 6063, a commonly used aluminum alloy known for its balance of strength, extrudability, and corrosion resistance.
  • Dimensions:
    • Internal Measurement: 8mm
    • Thickness: 3mm
    • Width: 25mm
    • Height: 9mm
  • Weight per Meter: 1.75 kg, indicating a relatively heavier profile suitable for applications requiring additional strength and support.

Specifications

Maximum Length 5 Metres
Material Aluminium
Weldability Fair
Shape Channel
Corrosion Resistance Excellent
Finish Mill Finish
Grade 6063
Internal measurement 8mm
Thickness 3mm
Width 25mm
Weight/Metre (Kg) 1.75

Key features

  • Grade 6063 (EN AW-6063, architectural aluminium alloy)
  • Excellent corrosion resistance
  • Fair weldability
  • Cut to the metres you order
FAQs

FAQs

Before you order

What does one unit of this item supply?

Quantity 1 = 1 metre. Up to 5 m comes as one piece; longer totals are supplied in pieces of up to 5 m.

Can you supply other sizes or a cutting list?

Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.

Specifications

Specifications

Product dimensions

Dimensions and supply details for this aluminium channel
Size25 × 9 × 3 mm
Sold byThe metre — cut to your length
Longest single piece5 m
Weight1.75 kg/m
FinishMill Finish
Grade6063
SKU—

Material properties

Material properties
Maximum Length5 Metres
MaterialAluminium
WeldabilityFair
ShapeChannel
Corrosion ResistanceExcellent
Internal measurement8mm
Thickness3mm
Width25mm

Catalogue name 25mm x 9mm x 3mm Aluminium Double Channel Mill Finish 6063 - Heavy Duty, Corrosion-Resistant, Ideal for Shelving & Mounting Brackets

Technical data (EN AW-6063)

Technical data · alloy

6063 / EN AW-6063

  • Si 0.2–0.6%Silicon
  • Mg 0.45–0.9%Magnesium
Alloy
Architectural aluminium alloy
Designation
EN AW-6063
Density
2.70 g/cm³

Typical composition for the grade, for guidance — not a mill certificate for this item.
