EN AW-6063 · Architectural aluminium alloy

6063 Aluminium Round Tube

31.7 mm OD × 1.6 mm wall (1 1/4″ × 16swg)1000 mm length

Photo6063 Aluminium Round Tube 31.7 mm OD × 1.6 mm wall (1 1/4″ × 16swg) – photo 1 of 2
Photo6063 Aluminium Round Tube 31.7 mm OD × 1.6 mm wall (1 1/4″ × 16swg) – photo 2 of 2
Dimensions Cross-section of a 31.7 mm OD × 1.6 mm wall (1 1/4″ × 16swg) tube Outside diameter 31.7 mm, wall thickness 1.6 mm, inside diameter 28.5 mm (calculated). OD 31.7 mm ID 28.5 mm* Wall 1.6 mm

OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall

£14.69incl. VATper 1000 mm length

Quantity 1 = one 1000 mm length of 31.7 mm OD × 1.6 mm wall (1 1/4″ × 16swg).

LengthSupplied as one length

Item total £14.69 1 × £14.69 per 1000 mm length

Secure checkout: Card, Apple Pay, Google Pay or Shop Pay

Availability
Available to order
Delivery
UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
Returns
Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Call 01744 520110Mon – Fri: 08:30 – 17:00 Email about this itemsales@industrialsafety-uk.co.uk
Overview

Overview

About this aluminium round tube

This high-performance aluminium round tube is manufactured from grade 6063 T6 alloy, a medium strength material known for its excellent mechanical properties and corrosion resistance. The addition of magnesium and silicon enhances its performance, making it ideal for a variety of applications.

Technical Specifications

  • Material: Aluminium alloy 6063 T6
  • Strength: Medium strength alloy
  • Weldability: Readily weldable
  • Heat Treatment: Heat treatable
  • Corrosion Resistance: Enhanced due to alloying elements

FAQs

Q: What are the main uses of the aluminium round tube?

A: This tube is widely used in architectural applications such as window and door frames, as well as industrial uses for signs and shop fittings.

Q: Can this tube be welded?

A: Yes, the 6063 T6 alloy is readily weldable, making it suitable for various fabrication needs.

Q: What enhances the corrosion resistance of this tube?

A: The addition of magnesium and silicon in the alloy composition improves its corrosion resistance significantly.

Applications

Applications

Where this round tube is used

The aluminium round tube is versatile and commonly used in:

  • Window frames
  • Door frames
  • Roofs
  • Signs
  • Shop fittings
  • Stair balustrades, rails, and posts
FAQs

FAQs

Before you order

What does one unit of this item supply?

Quantity 1 = one 1000 mm length of 31.7 mm OD × 1.6 mm wall (1 1/4″ × 16swg).

Can you supply other sizes or a cutting list?

Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.

Specifications

Specifications

Product dimensions

Dimensions and supply details for this aluminium round tube
Outside diameter (OD)31.7 mm
Wall thickness1.6 mm
Inside diameter (ID)28.5 mm calculated
Imperial size1 1/4″ × 16swg
Supplied length1000 mm
FinishNot stated
Grade6063
SKUAWH_IS2245

Catalogue name High-Performance 31.7mm x 1.6mm Aluminium Round Tube - Grade 6063 T6 Alloy for Architectural and Industrial Applications

Technical data (EN AW-6063)

Technical data · alloy

6063 / EN AW-6063

  • Si 0.2–0.6%Silicon
  • Mg 0.45–0.9%Magnesium
Alloy
Architectural aluminium alloy
Designation
EN AW-6063
Density
2.70 g/cm³

Typical composition for the grade, for guidance — not a mill certificate for this item.
