EN AW-6082 · Structural aluminium alloy
Premium Heavy Duty Aluminium Rectangular Tube 101.6mm x 76.2mm x 3.2mm - High-Strength Grade 6082 T6 for Versatile Applications
101.6 × 76.2 × 3.2 mm (4″ × 3″ × 10swg)1000 mm length
OD = outside diameter · ID = inside diameter
£131.92incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium rectangular tube
Product Overview
The Premium Heavy Duty Aluminium Rectangular Tube is crafted from high-strength grade 6082 T6, making it a superior choice among the 6000 Series aluminium alloys. This material is enhanced with magnesium, manganese, and silicon, which contributes to its excellent mechanical properties, ensuring both machinability and weldability.
Applications
This versatile rectangular tube is easily fabricated into various box and cubic shapes. It is ideal for a wide range of applications, including:
- Door and window frames
- Furniture construction
- Stands and supports
- Shop fittings and displays
- Stairs, balustrades, rails, and posts
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 101.6mm |
| Width | 76.2mm |
| Thickness | 3.2mm (10 SWG) |
Technical Specifications
- Material: Aluminium Grade 6082 T6
- Type: Rectangular Tube
- Strength: High-Strength 6000 Series
- Weldability: Excellent
- Machinability: Good
FAQs
- What is the maximum load capacity of this tube? The load capacity will depend on the specific application and design; please consult an engineer for structural requirements.
- Can this tube be painted or coated? Yes, the aluminium surface can be painted or coated for aesthetic or protective purposes.
- Is this tube suitable for outdoor use? Yes, aluminium is resistant to corrosion, making it suitable for outdoor applications.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | Not stated |
|---|---|
| Wall thickness | 3.2 (10 SWG) mm |
| Inside diameter (ID) | Not stated |
| Imperial size | 4″ × 3″ × 10swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS536 |
Material properties
| Width | 76.2mm |
|---|
Catalogue name Premium Heavy Duty Aluminium Rectangular Tube 101.6mm x 76.2mm x 3.2mm - High-Strength Grade 6082 T6 for Versatile Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
101.6 × 76.2 × 3.2 mm (4″ × 3″ × 10swg) £131.92 per 1000 mm length
