EN AW-6082 · Structural aluminium alloy
Premium Heavy Duty Aluminium Round Tube 114mm x 6.3mm - High Strength 6082 T6 Alloy for Structural Applications
114 mm OD × 6.3 mm wall (4 1/2″ × 1/4″)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
- Excellent corrosion resistance
£237.24incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 114 mm OD × 6.3 mm wall (4 1/2″ × 1/4″).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium round tube
Product Overview
This Premium Heavy Duty Aluminium Round Tube is designed for a variety of structural applications. Made from high-quality 6082 T6 alloy, this tube offers the highest strength within the 6000 series aluminium, making it suitable for demanding environments.
Key Features
- Alloy Grade: 6082 T6
- High strength and excellent corrosion resistance
- Solution heat-treated and artificially aged for optimal mechanical properties
- Versatile applications in structural fabrications
Applications
This Aluminium Round Tube is typically applied in:
- Highly stressed applications
- Transport systems
- Trusses
- Bridges
- Cranes
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Diameter | 114mm |
| Wall Thickness | 6.3mm |
Technical Specifications
- Material: Aluminium 6082 T6
- Corrosion Resistance: Excellent
- Mechanical Properties: Optimised through heat treatment
FAQs
-
What is the maximum load capacity of this aluminium tube?
The load capacity is determined by the application and design; consult an engineer for specific requirements. -
Is this tube suitable for outdoor use?
Yes, it has excellent corrosion resistance, making it suitable for outdoor applications. -
Can I cut this tube to size?
Yes, it can be cut to various lengths as needed for your project.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 114 mm OD × 6.3 mm wall (4 1/2″ × 1/4″).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 114 mm |
|---|---|
| Wall thickness | 6.3 mm |
| Inside diameter (ID) | 101.4 mm calculated |
| Imperial size | 4 1/2″ × 1/4″ |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS843 |
Catalogue name Premium Heavy Duty Aluminium Round Tube 114mm x 6.3mm - High Strength 6082 T6 Alloy for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
114 mm OD × 6.3 mm wall (4 1/2″ × 1/4″) £237.24 per 1000 mm length
