EN AW-6082 · Structural aluminium alloy
Premium Heavy Duty Aluminium Round Tube 57.2mm x 3.2mm in Alloy Grade 6082 T6 for Structural Applications
57.2 mm OD × 3.2 mm wall (2 1/4″ × 10swg)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
- Excellent corrosion resistance
£69.64incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 57.2 mm OD × 3.2 mm wall (2 1/4″ × 10swg).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium round tube
Product Overview
This Premium Aluminium Round Tube is made from alloy grade 6082 T6, known for its exceptional strength and durability. The T6 temper involves solution heat treatment and artificial aging, which optimizes its mechanical properties while ensuring excellent corrosion resistance.
Applications
Our Aluminium Round Tube is typically applied in various structural fabrications, including:
- Highly stressed applications
- Transport
- Trusses
- Bridges
- Cranes
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Diameter | 57.2mm |
| Wall Thickness | 3.2mm |
| Alloy Grade | 6082 T6 |
Technical Specifications
This round tube exhibits remarkable properties that make it suitable for a wide range of applications:
- High strength-to-weight ratio
- Excellent corrosion resistance
- Good weldability
- Suitable for high-stress environments
FAQs
What is the maximum load capacity of this aluminium tube?
The load capacity will depend on the specific application and support conditions; however, it is designed for high-stress uses.
Can this tube be used for outdoor applications?
Yes, the excellent corrosion resistance makes it suitable for outdoor and marine environments.
How is this aluminium tube best cut?
This tube can be cut using standard metal cutting tools, such as a saw or cutting torch, depending on the thickness and desired finish.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 57.2 mm OD × 3.2 mm wall (2 1/4″ × 10swg).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 57.2 mm |
|---|---|
| Wall thickness | 3.2 mm |
| Inside diameter (ID) | 50.8 mm calculated |
| Imperial size | 2 1/4″ × 10swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS803 |
Material properties
| Alloy Grade | 6082 T6 |
|---|
Catalogue name Premium Heavy Duty Aluminium Round Tube 57.2mm x 3.2mm in Alloy Grade 6082 T6 for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
57.2 mm OD × 3.2 mm wall (2 1/4″ × 10swg) £69.64 per 1000 mm length
