Product Overview
This Premium Residual Current Circuit Breaker (RCBO) is designed to provide high-level electrical safety with a rated current of 20 Amps and a rated residual operating current of 30mA. It features a 1P+N configuration and is suitable for various applications where electrical protection is crucial.
Key Features
- Type: Electro-magnetic type
- Residual current characteristics: A
- Pole Number: 1P+N
- Tripping Curve: C
- Rated Short-Circuit Capacity: 10kA
- Rated Voltage: 240V AC
- Rated Frequency: 50/60Hz
- Tripping Duration: Instantaneous (0.1s)
- Electro-mechanical Endurance: 4000 cycles
- Connection Terminal: Pillar terminal with clamp
- Connection Capacity: Rigid conductor 16mm
- Terminal Connection Height: 21.5mm
Technical Specifications
| Specification | Measurement |
|---|---|
| Rated Current | 20/40A |
| Rated Voltage | 240V AC |
| Rated Frequency | 50/60Hz |
| Tripping Duration | 0.1s |
| Electro-mechanical Endurance | 4000 cycles |
Frequently Asked Questions
- What is the purpose of an RCBO? An RCBO provides protection against both earth faults and overloads, ensuring safety in electrical circuits.
- How do I know if this RCBO is suitable for my application? Check the specifications such as voltage, current rating, and tripping characteristics to ensure compatibility with your electrical system.
- What is the significance of the tripping curve? The tripping curve indicates the response time of the RCBO to overload conditions, with type C being suitable for equipment with high inrush currents.
