EN AW-6082 · Structural aluminium alloy
Premium 30mm x 30mm x 3mm Aluminium Angle - Heavy Duty Grade 6082 T6 for Structural Applications
30 × 30 × 3 mm1000 mm length
30 × 30 × 3 mm
- Excellent corrosion resistance
£18.12incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium angle
Product Overview
This Premium Aluminium Angle is made from Grade 6082 T6 aluminium, a medium strength alloy known for its excellent corrosion resistance. With enhanced mechanical properties due to the addition of magnesium, manganese, and silicon, this material is highly regarded for its good machinability and weldability. The 6082 alloy is the highest strength grade in the 6000 series, making it ideal for various structural applications.
Typical Uses
- Frame building
- Automotive components and trims
- Cranes
- Trusses
- Bridges
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 30mm |
| Width | 30mm |
| Thickness | 3mm |
Technical Specifications
- Material: Grade 6082 T6 Aluminium
- Corrosion Resistance: Excellent
- Weldability: Good
- Machinability: Good
Frequently Asked Questions
What is the maximum load capacity of the aluminium angle?
The load capacity will depend on the specific application and setup. It is advisable to consult an engineer for precise calculations based on your project.
Can this aluminium angle be painted?
Yes, the surface can be painted, but it is recommended to prepare the surface properly to ensure adhesion.
Is this aluminium angle suitable for outdoor use?
Yes, due to its excellent corrosion resistance, it is highly suitable for outdoor applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 30 × 30 × 3 mm |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS2557 |
Material properties
| Width | 30mm |
|---|---|
| Thickness | 3mm |
Catalogue name Premium 30mm x 30mm x 3mm Aluminium Angle - Heavy Duty Grade 6082 T6 for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
30 × 30 × 3 mm £18.12 per 1000 mm length
