EN AW-6082 · Structural aluminium alloy
Premium 38.1mm x 38.1mm x 6.3mm Aluminium Angle - High-Performance Grade 6082 T6 for Structural Applications
38.1 × 38.1 × 6.3 mm (1 1/2″ × 1 1/2″ × 1/4″)1000 mm length
38.1 × 38.1 × 6.3 mm
- Excellent corrosion resistance
£58.56incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium angle
Product Overview
This Premium Aluminium Angle measures 38.1mm x 38.1mm x 6.3mm and is crafted from Grade 6082 T6 aluminium, a medium strength alloy known for its excellent corrosion resistance. The alloy's mechanical properties are enhanced through a combination of magnesium, manganese, and silicon, allowing for superior machinability and weldability. As the highest strength grade within the 6000 series, this material is ideal for various structural applications.
Typical Uses
- Frame building
- Automotive components & trims
- Cranes
- Trusses
- Bridges
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 38.1mm |
| Width | 38.1mm |
| Thickness | 6.3mm |
Technical Specifications
- Material: Grade 6082 T6 Aluminium
- Corrosion Resistance: Excellent
- Machinability: Good
- Weldability: Good
FAQs
Q: What is Grade 6082 T6 aluminium used for?
A: It is widely used for structural applications due to its high strength and good corrosion resistance.
Q: Can this aluminium angle be welded?
A: Yes, Grade 6082 T6 aluminium is known for its good weldability.
Q: What dimensions does this aluminium angle come in?
A: This aluminium angle measures 38.1mm x 38.1mm x 6.3mm.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 38.1 × 38.1 × 6.3 mm (1 1/2″ × 1 1/2″ × 1/4″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS291 |
Material properties
| Width | 38.1mm |
|---|---|
| Thickness | 6.3mm |
Catalogue name Premium 38.1mm x 38.1mm x 6.3mm Aluminium Angle - High-Performance Grade 6082 T6 for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
38.1 × 38.1 × 6.3 mm (1 1/2″ × 1 1/2″ × 1/4″) £58.56 per 1000 mm length
