EN AW-6082 · Structural aluminium alloy
Premium 25.4mm x 50.8mm x 3.2mm Plain Finish Aluminium Channel - High-Strength 6082 T6 U Channel for Structural Applications
25.4 × 50.8 × 3.2 mm (1″ × 2″ × 1/8″)1000 mm length
25.4 × 50.8 × 3.2 mm
- Excellent corrosion resistance
- Easy to machine
£51.98incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium channel
Product Overview
This premium aluminium channel, also known as a 'U Channel', is made from high-strength 6082 T6 alloy, which is part of the 6000 Series. The material features enhanced mechanical and corrosion resistance properties, thanks to the addition of magnesium, manganese, and silicon. It also retains excellent machinability and weldability, making it suitable for various demanding applications.
Applications
The 6082 T6 aluminium channel is ideal for use in highly stressed applications, including:
- Trusses
- Bridges
- Cranes
- Transport applications
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 50.8mm |
| Width | 25.4mm |
| Thickness | 3.2mm (1/8") |
Technical Specifications
The 6082 T6 aluminium channel provides exceptional performance in various structural applications:
- High strength-to-weight ratio
- Excellent corrosion resistance
- Good weldability and machinability
- Suitable for welding and fabrication
Frequently Asked Questions
What is the maximum load capacity of the 6082 T6 aluminium channel?
The load capacity depends on the specific application and installation method. It is recommended to consult a structural engineer for precise calculations.
Can this aluminium channel be painted or anodized?
Yes, the surface of the aluminium channel can be painted or anodized for additional protection and aesthetic purposes.
Is the aluminium channel suitable for outdoor use?
Yes, due to its corrosion-resistant properties, this aluminium channel is suitable for outdoor applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 25.4 × 50.8 × 3.2 mm (1″ × 2″ × 1/8″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS164 |
Material properties
| Width | 25.4mm |
|---|---|
| Thickness | 3.2mm (1/8") |
Catalogue name Premium 25.4mm x 50.8mm x 3.2mm Plain Finish Aluminium Channel - High-Strength 6082 T6 U Channel for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
25.4 × 50.8 × 3.2 mm (1″ × 2″ × 1/8″) £51.98 per 1000 mm length
