EN AW-6082 · Structural aluminium alloy
Premium Structural Alloy Aluminium Channel 50.8mm x 25.4mm x 3.2mm - High Strength 6082 T6 for Architectural and Commercial Applications
50.8 × 25.4 × 3.2 mm (2″ × 1″ × 1/8″)2500 mm length
50.8 × 25.4 × 3.2 mm
- Easy to machine
£132.63incl. VATper 2500 mm length
Quantity 1 = one 2500 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium channel
Product Overview
This Premium Structural Alloy Aluminium Channel, also known as 'U Channel', is crafted from high-strength grade 6082 T6 aluminium. This grade represents the highest strength within the 6000 series, enhanced with additions of magnesium, manganese, and silicon, which improve both mechanical properties and corrosion resistance while maintaining excellent machinability and weldability.
Applications
The 6082 T6 Aluminium Channel is designed for highly stressed applications, making it suitable for:
- Trusses
- Bridges
- Cranes
- Transport applications
Features
This brushed polished aluminium channel is versatile and can be used for a wide range of architectural and commercial applications. Its attractive satin brushed finish not only provides aesthetic appeal but also ensures an easy-to-clean surface while offering high corrosion resistance.
Note: The channel is polished on the three outside faces and the two edges only.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 50.8mm |
| Width | 25.4mm |
| Thickness | 3.2mm |
Technical Specifications
The 6082 T6 aluminium channel exhibits excellent mechanical properties, making it ideal for demanding structural applications:
- High strength-to-weight ratio
- Corrosion resistant
- Good machinability
- Excellent weldability
FAQ
Q: What is the primary use of the 6082 T6 aluminium channel?A: It is primarily used in highly stressed applications such as trusses, bridges, and cranes.
Q: How is the finish of the aluminium channel?A: The channel features a brushed polished finish on the three outside faces and edges, providing a satin surface that is aesthetically pleasing and easy to clean.
Q: Is this aluminium channel suitable for outdoor use?A: Yes, its high corrosion resistance makes it suitable for various outdoor applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2500 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 50.8 × 25.4 × 3.2 mm (2″ × 1″ × 1/8″) |
|---|---|
| Supplied length | 2500 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS6795 |
Material properties
| Width | 25.4mm |
|---|---|
| Thickness | 3.2mm |
Catalogue name Premium Structural Alloy Aluminium Channel 50.8mm x 25.4mm x 3.2mm - High Strength 6082 T6 for Architectural and Commercial Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
50.8 × 25.4 × 3.2 mm (2″ × 1″ × 1/8″) £132.63 per 2500 mm length
