EN AW-6082 · Structural aluminium alloy
Premium Brushed Polished Aluminium Channel 50.8mm x 38.1mm x 6.3mm - High-Strength 6082 T6 for Structural Applications
50.8 × 38.1 × 6.3 mm (2″ × 1 1/2″ × 1/4″)Brushed polished2500 mm length
50.8 × 38.1 × 6.3 mm
- Easy to machine
£226.49incl. VATper 2500 mm length
Quantity 1 = one 2500 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium channel
Product Overview
This Premium Aluminium Channel, also known as 'U Channel', is constructed from high-strength grade 6082 T6 aluminium. This alloy is recognized for its superior mechanical properties, including enhanced corrosion resistance, making it suitable for a variety of demanding applications.
Key Features
- Material: High-Strength 6082 T6 Aluminium
- Dimensions: 50.8mm x 38.1mm x 6.3mm (2" x 1 1/2" x 1/4")
- Brushed polished finish for an attractive appearance and easy cleaning
- Polished on three outside faces and two edges for a refined look
- Excellent machinability and weldability
Applications
This versatile aluminium channel is ideal for:
- Trusses
- Bridges
- Cranes
- Transport applications
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 50.8mm |
| Width | 38.1mm |
| Thickness | 6.3mm |
Technical Specifications
- Grade: 6082 T6
- Finish: Brushed Polished
- Corrosion Resistance: High
- Machinability: Excellent
- Weldability: Good
Frequently Asked Questions
Q: What is the maximum load capacity of the aluminium channel?A: The maximum load capacity depends on the specific application and configuration. It is advisable to consult with an engineer for precise load calculations.
Q: Can this channel be used for outdoor applications?A: Yes, the high corrosion resistance of the 6082 T6 aluminium makes it suitable for outdoor use.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2500 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 50.8 × 38.1 × 6.3 mm (2″ × 1 1/2″ × 1/4″) |
|---|---|
| Supplied length | 2500 mm |
| Finish | Brushed polished |
| Grade | 6082 |
| SKU | AWH_IS6805 |
Material properties
| Width | 38.1mm |
|---|---|
| Thickness | 6.3mm |
Catalogue name Premium Brushed Polished Aluminium Channel 50.8mm x 38.1mm x 6.3mm - High-Strength 6082 T6 for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
50.8 × 38.1 × 6.3 mm (2″ × 1 1/2″ × 1/4″) £226.49 per 2500 mm length
