EN AW-6082 · Structural aluminium alloy
Premium Structural Alloy Aluminium Channel 50.8mm x 50.8mm x 4.8mm - High Strength 6082 T6 with Brushed Polished Finish for Architectural Applications
50.8 × 50.8 × 4.8 mm (2″ × 2″ × 3/16″)Brushed polished2500 mm length
50.8 × 50.8 × 4.8 mm
- Excellent corrosion resistance
£253.32incl. VATper 2500 mm length
Quantity 1 = one 2500 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium channel
Product Overview
The Premium Structural Alloy Aluminium Channel, also known as 'U Channel', is manufactured from high-strength 6082 T6 aluminum. This alloy is renowned for its mechanical properties and excellent corrosion resistance due to the addition of magnesium, manganese, and silicon. It offers good machinability and weldability, making it suitable for challenging applications.
Applications
6082 T6 aluminum is ideal for highly stressed applications, including:
- Trusses
- Bridges
- Cranes
- Transport applications
Finish and Aesthetics
This brushed polished aluminium channel features an attractive satin finish, providing a clean and modern appearance. It is perfect for decorative purposes and easy to clean, while also offering high corrosion resistance.
*Polished on the three outside faces and the two edges only.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 50.8mm |
| Width | 50.8mm |
| Thickness | 4.8mm (3/16") |
| Material Grade | 6082 T6 |
Technical Specifications
- Material: Aluminium Alloy 6082 T6
- Corrosion Resistant: Yes
- Machinability: Good
- Weldability: Good
FAQs
Q: What is the maximum load capacity of this aluminium channel?
A: The load capacity will depend on the specific application and installation method. It's recommended to consult with a structural engineer for precise load calculations.
Q: Can this channel be used for outdoor applications?
A: Yes, the high corrosion resistance of the 6082 T6 alloy makes it suitable for outdoor use.
Q: Is this product easy to cut and shape?
A: Yes, the aluminium channel offers good machinability, allowing for easy cutting and shaping as needed.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2500 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 50.8 × 50.8 × 4.8 mm (2″ × 2″ × 3/16″) |
|---|---|
| Supplied length | 2500 mm |
| Finish | Brushed polished |
| Grade | 6082 |
| SKU | AWH_IS6809 |
Material properties
| Width | 50.8mm |
|---|---|
| Thickness | 4.8mm (3/16") |
| Material Grade | 6082 T6 |
Catalogue name Premium Structural Alloy Aluminium Channel 50.8mm x 50.8mm x 4.8mm - High Strength 6082 T6 with Brushed Polished Finish for Architectural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
50.8 × 50.8 × 4.8 mm (2″ × 2″ × 3/16″) £253.32 per 2500 mm length
