EN AW-6082 · Structural aluminium alloy
Premium 76.2mm x 50.8mm x 3.2mm Plain Finish Aluminium Channel - Structural Alloy 6082 T6 for High-Performance Applications
76.2 × 50.8 × 3.2 mm (3″ × 2″ × 1/8″)1000 mm length
76.2 × 50.8 × 3.2 mm
- Excellent corrosion resistance
£68.88incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium channel
Product Overview
This Premium Aluminium Channel, also known as 'U Channel', is made from the high-strength 6082 T6 structural alloy. This grade of aluminium is part of the 6000 series, known for its excellent mechanical properties and corrosion resistance. The specific alloy composition includes magnesium, manganese, and silicon, which enhance durability while maintaining machinability and weldability.
Applications
The 6082 T6 aluminium channel is ideal for various highly stressed applications, including:
- Trusses
- Bridges
- Cranes
- Transport applications
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 76.2mm |
| Width | 50.8mm |
| Thickness | 3.2mm |
Technical Specifications
The following technical specifications highlight the features of the Premium Aluminium Channel:
- Material: Aluminium Alloy 6082 T6
- Grade: High-Strength
- Corrosion Resistance: Excellent
- Machinability: Good
- Weldability: Good
FAQ
Q: What is the main advantage of using 6082 T6 aluminium?A: The main advantage is its high strength and excellent corrosion resistance, making it suitable for demanding applications.
Q: Can this aluminium channel be welded?
A: Yes, it has good weldability, allowing for easy integration into various structures.
Q: What are the common uses of this aluminium channel?
A: Common uses include construction of trusses, bridges, cranes, and various transport applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 76.2 × 50.8 × 3.2 mm (3″ × 2″ × 1/8″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS219 |
Material properties
| Width | 50.8mm |
|---|---|
| Thickness | 3.2mm |
Catalogue name Premium 76.2mm x 50.8mm x 3.2mm Plain Finish Aluminium Channel - Structural Alloy 6082 T6 for High-Performance Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
76.2 × 50.8 × 3.2 mm (3″ × 2″ × 1/8″) £68.88 per 1000 mm length
