EN AW-6082 · Structural aluminium alloy
6082 Aluminium Flat Bar
101.6 × 4.8 mm (4″ × 3/16″)2500 mm length
- Excellent corrosion resistance
- Easy to machine
£136.66incl. VATper 2500 mm length
Quantity 1 = one 2500 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium flat bar
The Premium Structural Grade 6082 T6 Aluminium Flat Bar is the highest strength alloy in the 6000 Series. With additions of magnesium, manganese, and silicon, both mechanical and corrosion resistance properties are enhanced while maintaining excellent machinability and weldability.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
- Easy to machine
Finish and Features
This dull polished aluminium flat bar is suitable for a wide range of architectural and commercial applications. The attractive satin brushed-like surface is ideal for decorative purposes and offers an easy-to-clean surface with high corrosion resistance.
*All four faces are polished.
Technical Specifications
The 6082 T6 Aluminium Flat Bar combines superior strength with excellent corrosion resistance, making it a reliable choice for demanding applications.
FAQs
-
What is the primary use of the 6082 T6 Aluminium Flat Bar?
It is primarily used in structural applications, including trusses and bridges. -
How does the finish affect the aluminium bar?
The brushed polished finish provides an attractive look and enhances corrosion resistance. -
Is the aluminium bar easy to machine?
Yes, it retains good machinability due to its alloy composition.
Applications
Applications
Where this flat bar is used
6082 T6 is suited for highly stressed applications including:
- Trusses
- Bridges
- Cranes
- Automotive components
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2500 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 101.6 × 4.8 mm (4″ × 3/16″) |
|---|---|
| Supplied length | 2500 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS6996 |
Material properties
| Width | 4.8mm |
|---|---|
| Material | 6082 T6 Aluminium |
Catalogue name Premium Structural Grade 6082 T6 Aluminium Flat Bar 101.6mm x 4.8mm for High-Stress Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
101.6 × 4.8 mm (4″ × 3/16″) £136.66 per 2500 mm length
