EN AW-6063 · Architectural aluminium alloy
Premium 19mm x 3.2mm Aluminium Flat Bar - High-Performance 6063 T6 Alloy with Excellent Corrosion Resistance and Weldability
19 × 3.2 mm (3/4″ × 1/8″)1000 mm length
£21.08incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium flat bar
Product Overview
This Premium Aluminium Flat Bar measures 19mm x 3.2mm and is crafted from high-performance 6063 T6 aluminium alloy. Known for its medium strength and versatility, this aluminium flat bar is ideal for various architectural and industrial applications.
Features and Benefits
- Material: 6063 T6 Aluminium Alloy
- Strength: Medium strength alloy with good mechanical properties
- Corrosion Resistance: High resistance to corrosion, ensuring longevity
- Weldability: Readily weldable for various construction needs
- Heat Treatable: Can be heat treated to enhance performance
Applications
This aluminium flat bar is commonly used in:
- Window frames
- Door frames
- Roofs
- Signs
- Shop fittings
- Stair balustrades, rails & posts
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Width | 19mm |
| Thickness | 3.2mm |
Technical Specifications
- Alloy Type: 6063 T6
- Mechanical Properties: Good
- Corrosion Resistance: High
- Weldability: Readily weldable
FAQs
Q: Is this aluminium flat bar suitable for outdoor use?A: Yes, the high corrosion resistance makes it ideal for outdoor applications.
Q: Can I weld this aluminium flat bar?A: Absolutely! It is readily weldable for various construction projects.
Q: What are the common applications for this product?A: It is commonly used for window frames, door frames, roofs, signs, and more.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 19 × 3.2 mm (3/4″ × 1/8″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6063 |
| SKU | AWH_IS1363 |
Material properties
| Width | 19mm |
|---|---|
| Thickness | 3.2mm |
Catalogue name Premium 19mm x 3.2mm Aluminium Flat Bar - High-Performance 6063 T6 Alloy with Excellent Corrosion Resistance and Weldability
Technical data (EN AW-6063)
Technical data · alloy
6063 / EN AW-6063
- Si 0.2–0.6%Silicon
- Mg 0.45–0.9%Magnesium
- Alloy
- Architectural aluminium alloy
- Designation
- EN AW-6063
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
19 × 3.2 mm (3/4″ × 1/8″) £21.08 per 1000 mm length
