EN AW-6082 · Structural aluminium alloy
Premium 50mm x 10mm Structural Grade Aluminium Flat Bar - High Strength 6082 T6 Alloy for Durable Applications
50 × 10 mm1000 mm length
- Excellent corrosion resistance
£104.96incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium flat bar
Product Overview
This premium structural grade aluminium flat bar is crafted from the high-strength 6082 T6 alloy, which is recognized as the highest strength alloy in the 6000 Series. Enhanced with magnesium, manganese, and silicon, this alloy boasts excellent mechanical and corrosion resistance, while also maintaining good machinability and weldability.
Applications
The 6082 T6 aluminium flat bar is ideal for highly stressed applications, including:
- Trusses
- Bridges
- Cranes
- Automotive components
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Width | 50mm |
| Thickness | 10mm |
Technical Specifications
- Alloy Type: 6082 T6
- Mechanical Properties: High strength, good machinability, and weldability
- Corrosion Resistance: Excellent
FAQs
What is the main use of the 6082 T6 aluminium flat bar?
This flat bar is primarily used in applications that require high strength, such as structural components, automotive parts, and bridges.
Can this aluminium flat bar be welded?
Yes, the 6082 T6 alloy offers good weldability, making it suitable for various fabrication processes.
Is this flat bar resistant to corrosion?
Absolutely! The 6082 T6 alloy is known for its excellent corrosion resistance, making it ideal for outdoor and marine applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 50 × 10 mm |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS2536 |
Material properties
| Width | 50mm |
|---|---|
| Thickness | 10mm |
Catalogue name Premium 50mm x 10mm Structural Grade Aluminium Flat Bar - High Strength 6082 T6 Alloy for Durable Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
50 × 10 mm £104.96 per 1000 mm length
