EN AW-6082 · Structural aluminium alloy
6082 Aluminium Flat Bar
60 × 5 mm2000 mm length
- Easy to machine
£120.52incl. VATper 2000 mm length
Quantity 1 = one 2000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium flat bar
Product Overview The Premium Structural Grade 6082 T6 Aluminium Flat Bar is crafted from the highest strength alloy in the 6000 Series. Enhanced with magnesium, manganese, and silicon, this flat bar exhibits superior mechanical and corrosion resistance properties, while also maintaining excellent machinability and weldability.
Applications 6082 T6 is ideal for highly stressed applications including:
Dimensions & Specifications
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Easy to machine
Technical Specifications
- Corrosion Resistance: High
- Machinability: Excellent
- Weldability: Good
- Finish: Satin brushed
Frequently Asked Questions
What is the maximum load capacity of this flat bar?
The load capacity depends on the specific application and design, but 6082 T6 is known for its high strength in structural applications.
Can this aluminium flat bar be cut to size?
Yes, the flat bar can be cut to various sizes as per your project requirements.
Is this flat bar suitable for outdoor use?
Yes, the high corrosion resistance makes it ideal for outdoor applications.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 60 × 5 mm |
|---|---|
| Supplied length | 2000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS6976 |
Material properties
| Width | 5mm |
|---|---|
| Material | 6082 T6 Aluminium |
Catalogue name Premium Structural Grade 6082 T6 Aluminium Flat Bar 60mm x 5mm - High Strength, Corrosion Resistant, Ideal for Trusses and Bridges
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
60 × 5 mm £120.52 per 2000 mm length
