EN AW-6082 · Structural aluminium alloy
6082 Aluminium Flat Bar
63.5 × 4.8 mm (2 1/2″ × 3/16″)2000 mm length
- Excellent corrosion resistance
£139.75incl. VATper 2000 mm length
Quantity 1 = one 2000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium flat bar
The Premium Structural Grade 6082 T6 Aluminium Flat Bar is crafted from the highest strength alloy in the 6000 Series. Enhanced with magnesium, manganese, and silicon, this alloy offers exceptional mechanical strength and excellent corrosion resistance while maintaining good machinability and weldability.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
Finish and Features
The dull polished surface of this aluminium flat bar provides an attractive satin-like finish, making it suitable for architectural and commercial applications. Its easy-to-clean surface combined with high corrosion resistance ensures longevity and durability.
*All four faces are polished for a uniform appearance.
Technical Specifications
- Alloy: 6082 T6
- Corrosion Resistance: High
- Machinability: Good
- Weldability: Good
FAQ
What is the primary use of the 6082 T6 Aluminium Flat Bar?
The 6082 T6 Aluminium Flat Bar is primarily used in applications that require high strength, such as construction and automotive components.
How does the finish affect its usability?
The brushed polished finish not only enhances the aesthetic appeal but also provides a surface that is easy to clean and maintains its appearance over time.
Is this aluminium flat bar suitable for outdoor use?
Yes, its high corrosion resistance makes it suitable for outdoor applications.
Applications
Applications
Where this flat bar is used
This versatile flat bar is ideal for a range of highly stressed applications, including:
- Trusses
- Bridges
- Cranes
- Automotive components
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 63.5 × 4.8 mm (2 1/2″ × 3/16″) |
|---|---|
| Supplied length | 2000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS6982 |
Material properties
| Width | 63.5mm |
|---|---|
| Thickness | 4.8mm |
| Alloy Type | 6082 T6 |
Catalogue name Premium Structural Grade 6082 T6 Aluminium Flat Bar 63.5mm x 4.8mm for High-Stress Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
63.5 × 4.8 mm (2 1/2″ × 3/16″) £139.75 per 2000 mm length
