EN AW-6082 · Structural aluminium alloy
6082 Aluminium Flat Bar
88.9 × 6.3 mm (3 1/2″ × 1/4″)2500 mm length
- Easy to machine
£264.76incl. VATper 2500 mm length
Quantity 1 = one 2500 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium flat bar
This Premium Structural grade Aluminium Flat Bar, measuring 88.9mm x 6.3mm (3 1/2" x 1/4"), is crafted from the high-strength 6082 T6 alloy. This alloy is renowned for its mechanical properties and enhanced corrosion resistance due to the addition of magnesium, manganese, and silicon. It offers excellent machinability and weldability, making it an ideal choice for various applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Easy to machine
Features
- High-Performance 6082 T6 Aluminium Alloy
- Polished finish for aesthetic appeal
- Corrosion-resistant for longevity
- Easy to clean surface
- All four faces are polished for a uniform look
Technical Specifications
- Material: 6082 T6 Aluminium
- Finish: Polished, Satin Brushed Surface
- Corrosion Resistance: High
- Machinability: Excellent
- Weldability: Good
Frequently Asked Questions
What is the weight of the aluminium flat bar?
The weight can vary based on length and is typically calculated based on the density of the aluminium alloy.
Can this flat bar be used for outdoor applications?
Yes, the high corrosion resistance makes it suitable for outdoor use in various applications.
Is this flat bar easy to machine?
Yes, the 6082 T6 alloy offers excellent machinability.
Applications
Applications
Where this flat bar is used
6082 T6 is suitable for highly stressed applications including:
- Trusses
- Bridges
- Cranes
- Automotive components
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 2500 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 88.9 × 6.3 mm (3 1/2″ × 1/4″) |
|---|---|
| Supplied length | 2500 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS6992 |
Material properties
| Width | 6.3mm |
|---|
Catalogue name Premium Structural Aluminium Flat Bar 88.9mm x 6.3mm - High-Performance 6082 T6 Alloy with Corrosion Resistance for Architectural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
88.9 × 6.3 mm (3 1/2″ × 1/4″) £264.76 per 2500 mm length
