EN AW-6082 · Structural aluminium alloy
Premium Aluminium Rectangular Tube 50.8mm x 25.4mm x 1.6mm - High-Performance Grade 6082 T6 for Versatile Applications
50.8 × 25.4 × 1.6 mm (2″ × 1″ × 16swg)1000 mm length
OD = outside diameter · ID = inside diameter
- Easy to machine
£33.94incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium rectangular tube
Product Overview
The Premium Aluminium Rectangular Tube is crafted from high-strength grade 6082 T6, which is renowned for its superior mechanical properties. This premium material is enhanced with magnesium, manganese, and silicon, ensuring excellent machinability and weldability. The rectangular tube can be easily fabricated into box or cubic shapes, making it highly versatile for various applications.
Applications
This high-performance rectangular tube is suitable for a wide range of applications including:
- Door and window frames
- Furniture construction
- Display stands
- Shop fittings
- Stairs, balustrades, rails, and posts
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 50.8mm |
| Width | 25.4mm |
| Thickness | 1.6mm |
Technical Specifications
This aluminium rectangular tube features:
- Grade: 6082 T6
- High strength with excellent machinability
- Good weldability for diverse fabrication needs
Frequently Asked Questions
1. What is the main use of the aluminium rectangular tube?
The aluminium rectangular tube is commonly used in construction, furniture making, and various structural applications.
2. Can this tube be welded?
Yes, the 6082 T6 grade allows for good weldability, making it suitable for various fabrication processes.
3. What are the mechanical properties of grade 6082 T6?
Grade 6082 T6 offers high strength and excellent machinability due to its enhanced composition.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | Not stated |
|---|---|
| Wall thickness | 1.6 mm |
| Inside diameter (ID) | Not stated |
| Imperial size | 2″ × 1″ × 16swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS3631 |
Material properties
| Width | 25.4mm |
|---|
Catalogue name Premium Aluminium Rectangular Tube 50.8mm x 25.4mm x 1.6mm - High-Performance Grade 6082 T6 for Versatile Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
50.8 × 25.4 × 1.6 mm (2″ × 1″ × 16swg) £33.94 per 1000 mm length
