EN AW-6082 · Structural aluminium alloy
Premium 114mm x 3.2mm Aluminium Round Tube - High-Strength Alloy Grade 6082 T6 for Structural Applications
114 mm OD × 3.2 mm wall (4 1/2″ × 10swg)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
- Excellent corrosion resistance
£130.40incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 114 mm OD × 3.2 mm wall (4 1/2″ × 10swg).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium round tube
Product Overview
The Premium Aluminium Round Tube measures 114mm in diameter and 3.2mm in wall thickness. Crafted from high-strength alloy grade 6082 T6, this tube stands out due to its excellent mechanical properties, making it ideal for demanding structural applications.
Utilizing a solution heat treatment and artificial ageing process, the T6 temper optimizes the mechanical properties of the tube. This ensures not only superior strength but also excellent corrosion resistance, making it suitable for various applications.
Typical Applications
This aluminium round tube is typically used in:
- Highly stressed applications
- Transport constructions
- Trusses and frameworks
- Bridges and supporting structures
- Cranes and lifting equipment
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Diameter | 114mm |
| Wall Thickness | 3.2mm |
Technical Specifications
- Material: Aluminium Alloy 6082 T6
- Corrosion Resistance: Excellent
- Temper: T6 (solution heat treated and artificially aged)
FAQs
What is the maximum load rating for this tube?
The load rating will depend on the specific application and the configuration used. It is recommended to consult engineering guidelines for specific load calculations.
Can this tube be used in outdoor applications?
Yes, due to its excellent corrosion resistance, this aluminium round tube is suitable for both indoor and outdoor applications.
Is this tube available in other sizes?
Yes, this aluminium round tube is available in various sizes and specifications to meet different project requirements.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 114 mm OD × 3.2 mm wall (4 1/2″ × 10swg).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 114 mm |
|---|---|
| Wall thickness | 3.2 mm |
| Inside diameter (ID) | 107.6 mm calculated |
| Imperial size | 4 1/2″ × 10swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS838 |
Catalogue name Premium 114mm x 3.2mm Aluminium Round Tube - High-Strength Alloy Grade 6082 T6 for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
114 mm OD × 3.2 mm wall (4 1/2″ × 10swg) £130.40 per 1000 mm length
