EN AW-6082 · Structural aluminium alloy
Premium Aluminium Round Tube 127mm x 9.5mm - High-Performance 6082 T6 Alloy with Excellent Corrosion Resistance for Structural Applications
127 mm OD × 9.5 mm wall (5″ × 3/8″)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
- Excellent corrosion resistance
£455.99incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 127 mm OD × 9.5 mm wall (5″ × 3/8″).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium round tube
Product Overview
This Premium Aluminium Round Tube is crafted from 6082 T6 alloy, known for its exceptional strength within the 6000 series of aluminium. The T6 temper is achieved through a solution heat treatment and artificial ageing process, enhancing the mechanical properties of the tube. In addition to its outstanding strength, this round tube offers excellent corrosion resistance, making it suitable for a variety of demanding applications.
Typical Applications
The Aluminium Round Tube is typically applied in structural fabrications, including:
- Highly stressed applications
- Transport structures
- Trusses
- Bridges
- Cranes
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Outer Diameter | 127mm |
| Wall Thickness | 9.5mm |
Technical Specifications
The key features of this Premium Aluminium Round Tube include:
- Material: 6082 T6 Aluminium Alloy
- High strength and durability
- Excellent resistance to corrosion
- Ideal for structural and heavy-duty applications
Frequently Asked Questions
Q1: What is the primary use of the aluminium round tube?A1: This tube is primarily used in structural applications such as trusses, bridges, and cranes due to its high strength and corrosion resistance.
Q2: Can this tube be used outdoors?A2: Yes, the excellent corrosion resistance of this aluminium round tube makes it suitable for outdoor use in various environments.
Q3: What is the advantage of the T6 temper?A3: The T6 temper provides optimal mechanical properties through heat treatment, enhancing strength and durability, making it ideal for demanding applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 127 mm OD × 9.5 mm wall (5″ × 3/8″).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 127 mm |
|---|---|
| Wall thickness | 9.5 mm |
| Inside diameter (ID) | 108.0 mm calculated |
| Imperial size | 5″ × 3/8″ |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS3277 |
Material properties
| Outer Diameter | 127mm |
|---|
Catalogue name Premium Aluminium Round Tube 127mm x 9.5mm - High-Performance 6082 T6 Alloy with Excellent Corrosion Resistance for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
127 mm OD × 9.5 mm wall (5″ × 3/8″) £455.99 per 1000 mm length
