EN AW-6082 · Structural aluminium alloy
6082 Aluminium Round Tube
22.2 mm OD × 1.6 mm wall (7/8″ × 16swg)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
- Excellent corrosion resistance
£12.35incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 22.2 mm OD × 1.6 mm wall (7/8″ × 16swg).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium round tube
This Premium Aluminium Round Tube is crafted from alloy grade 6082 T6, renowned for its superior strength compared to other aluminium tubes in the 6000 series. The T6 temper is achieved through a solution heat treatment and artificial ageing process, optimizing its mechanical properties. In addition to its strength, this round tube boasts excellent corrosion resistance, making it ideal for various demanding applications.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
Technical Specifications
- High strength and durability
- Excellent corrosion resistance
- Optimized mechanical properties due to T6 treatment
Frequently Asked Questions
What is the maximum load capacity of this tube?
The maximum load capacity can vary based on the specific application and support conditions. It is recommended to consult structural engineering guidelines for precise calculations.
Can this tube be used for outdoor applications?
Yes, the excellent corrosion resistance of this aluminium round tube makes it suitable for outdoor use.
Is this tube available in different sizes?
This particular tube is offered in a diameter of 22.2mm with a wall thickness of 1.6mm. Other sizes may be available upon request.
Applications
Applications
Where this round tube is used
This versatile aluminium round tube is typically applied in structural fabrications, including:
- Highly stressed applications
- Transport systems
- Trusses
- Bridges
- Cranes
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 22.2 mm OD × 1.6 mm wall (7/8″ × 16swg).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 22.2 mm |
|---|---|
| Wall thickness | 1.6 mm |
| Inside diameter (ID) | 19.0 mm calculated |
| Imperial size | 7/8″ × 16swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS2190 |
Material properties
| Alloy Grade | 6082 T6 |
|---|
Catalogue name Premium 22.2mm x 1.6mm Aluminium Round Tube - High-Performance Alloy Grade 6082 T6 for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
22.2 mm OD × 1.6 mm wall (7/8″ × 16swg) £12.35 per 1000 mm length
