EN AW-6063 · Architectural aluminium alloy
6063 Aluminium Round Tube
25.4 mm OD × 1.2 mm wall (1″ × 18swg)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
£15.44incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 25.4 mm OD × 1.2 mm wall (1″ × 18swg).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium round tube
The Premium Aluminium Round Tube, measuring 25.4mm in diameter and 1.2mm in thickness, is crafted from high-quality 6063 T6 alloy. This medium-strength alloy is renowned for its excellent weldability and heat treatability, making it a preferred choice for architectural and industrial solutions. Enhanced with magnesium and silicon, it exhibits superior mechanical properties and corrosion resistance.
Technical Specifications
- Material: Aluminium 6063 T6
- Alloy Type: Medium strength
- Corrosion Resistance: Enhanced by magnesium and silicon
- Weldability: Readily weldable
- Heat Treatability: Heat treatable
Frequently Asked Questions
What is the main use of the 6063 T6 aluminium round tube?
The 6063 T6 aluminium round tube is primarily used in architectural applications such as window frames, door frames, and shop fittings due to its strength and corrosion resistance.
Can this aluminium tube be welded?
Yes, the aluminium round tube is readily weldable, making it ideal for various fabrication processes.
What enhances the corrosion resistance of this aluminium tube?
The addition of magnesium and silicon to the alloy improves its mechanical properties and provides enhanced corrosion resistance.
Applications
Applications
Where this round tube is used
This versatile aluminium round tube is suitable for a variety of applications, including:
- Window frames
- Door frames
- Roofs
- Signs
- Shop fittings
- Stair balustrades, rails & posts
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 25.4 mm OD × 1.2 mm wall (1″ × 18swg).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 25.4 mm |
|---|---|
| Wall thickness | 1.2 mm |
| Inside diameter (ID) | 23.0 mm calculated |
| Imperial size | 1″ × 18swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6063 |
| SKU | AWH_IS2195 |
Catalogue name Premium 25.4mm x 1.2mm Aluminium Round Tube - 6063 T6 Alloy for Architectural Applications
Technical data (EN AW-6063)
Technical data · alloy
6063 / EN AW-6063
- Si 0.2–0.6%Silicon
- Mg 0.45–0.9%Magnesium
- Alloy
- Architectural aluminium alloy
- Designation
- EN AW-6063
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
