EN AW-6063 · Architectural aluminium alloy
Premium 28.5mm x 1.2mm Aluminium Round Tube - Grade 6063 T6 for Architectural Solutions
28.5 mm OD × 1.2 mm wall (1 1/8″ × 18swg)1000 mm length
OD = outside diameter · ID = inside diameter · *ID calculated as OD − 2 × wall
£23.00incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 28.5 mm OD × 1.2 mm wall (1 1/8″ × 18swg).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium round tube
Product Overview
This Premium Aluminium Round Tube is made from grade 6063 T6, a medium strength alloy specifically designed for various architectural solutions. Known for its excellent weldability and heat treatability, this tube is enhanced with magnesium and silicon, providing superior mechanical properties and corrosion resistance.
Applications
The versatility of this aluminium round tube makes it ideal for a wide range of architectural and industrial applications, including:
- Window frames
- Door frames
- Roofs
- Signs
- Shop fittings
- Stair balustrades, rails & posts
Dimensions & Specifications
The specifications of the aluminium round tube are as follows:
| Specification | Measurement |
|---|---|
| Diameter | 28.5mm |
| Wall Thickness | 1.2mm |
| Material | Aluminium Grade 6063 T6 |
Technical Specifications
- Material Type: Aluminium
- Alloy Grade: 6063 T6
- Corrosion Resistance: Enhanced
- Weldability: Readily weldable
- Heat Treatability: Heat treatable
Frequently Asked Questions
1. What is the primary use of this aluminium round tube?
This tube is primarily used in architectural applications such as window and door frames, roofing, and signage.
2. Is this aluminium tube suitable for outdoor use?
Yes, the corrosion-resistant properties of the grade 6063 T6 alloy make it suitable for outdoor applications.
3. Can this tube be welded?
Yes, this aluminium round tube is readily weldable, making it versatile for various construction needs.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 28.5 mm OD × 1.2 mm wall (1 1/8″ × 18swg).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Outside diameter (OD) | 28.5 mm |
|---|---|
| Wall thickness | 1.2 mm |
| Inside diameter (ID) | 26.1 mm calculated |
| Imperial size | 1 1/8″ × 18swg |
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6063 |
| SKU | AWH_IS738 |
Material properties
| Material | Aluminium Grade 6063 T6 |
|---|
Catalogue name Premium 28.5mm x 1.2mm Aluminium Round Tube - Grade 6063 T6 for Architectural Solutions
Technical data (EN AW-6063)
Technical data · alloy
6063 / EN AW-6063
- Si 0.2–0.6%Silicon
- Mg 0.45–0.9%Magnesium
- Alloy
- Architectural aluminium alloy
- Designation
- EN AW-6063
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
28.5 mm OD × 1.2 mm wall (1 1/8″ × 18swg) £23.00 per 1000 mm length
