EN AW-6063 · Architectural aluminium alloy
Premium Aluminium Unequal Angle 31.7mm x 12.7mm x 3.2mm - Grade 6063 T6 Alloy for High Corrosion Resistance and Versatile Applications
31.7 × 12.7 × 3.2 mm (1 1/4″ × 1/2″ × 1/8″)3000 mm length
31.7 × 12.7 × 3.2 mm
£57.00incl. VATper 3000 mm length
Quantity 1 = one 3000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium angle
Product Overview
The Premium Aluminium Unequal Angle measures 31.7mm x 12.7mm x 3.2mm and is constructed from Grade 6063 T6 aluminium. This medium-strength alloy is recognized for its high corrosion resistance and good mechanical strength, making it an ideal choice for various applications.
Key Features
- Medium strength alloy with high corrosion resistance
- Good mechanical strength and heat treatable
- Compatible with welding and brazing
- Excellent formability for manufacturing processes
Typical Applications
The Premium Aluminium Unequal Angle is suited for a variety of architectural and industrial uses, including:
- Store fronts
- Frame building
- Automotive components and trims
- Cranes
- Trusses
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 31.7mm |
| Width | 12.7mm |
| Thickness | 3.2mm |
Technical Specifications
- Material: Grade 6063 T6 Aluminium
- Corrosion Resistance: High
- Weldable: Yes
- Formability: Excellent
FAQs
Q: Can this aluminium angle be welded?A: Yes, the Premium Aluminium Unequal Angle is suitable for welding and brazing.
Q: What is the primary benefit of using Grade 6063 T6 aluminium?A: This alloy offers high corrosion resistance and good mechanical strength, making it ideal for various applications.
Q: What are common uses for aluminium angles?A: They are commonly used in store fronts, frame building, automotive components, cranes, and trusses.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 3000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 31.7 × 12.7 × 3.2 mm (1 1/4″ × 1/2″ × 1/8″) |
|---|---|
| Supplied length | 3000 mm |
| Finish | Not stated |
| Grade | 6063 |
| SKU | AWH_IS940 |
Material properties
| Width | 12.7mm |
|---|---|
| Thickness | 3.2mm |
Catalogue name Premium Aluminium Unequal Angle 31.7mm x 12.7mm x 3.2mm - Grade 6063 T6 Alloy for High Corrosion Resistance and Versatile Applications
Technical data (EN AW-6063)
Technical data · alloy
6063 / EN AW-6063
- Si 0.2–0.6%Silicon
- Mg 0.45–0.9%Magnesium
- Alloy
- Architectural aluminium alloy
- Designation
- EN AW-6063
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
31.7 × 12.7 × 3.2 mm (1 1/4″ × 1/2″ × 1/8″) £57.00 per 3000 mm length
