EN AW-6063 · Architectural aluminium alloy
Premium 50.8mm x 25.4mm x 1.6mm Aluminium Unequal Angle - Grade 6063 T6 with High Corrosion Resistance for Versatile Applications
50.8 × 25.4 × 1.6 mm (2″ × 1″ × 1/16″)1000 mm length
50.8 × 25.4 × 1.6 mm
£29.14incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this aluminium angle
Product Overview
This premium aluminium unequal angle measures 50.8mm x 25.4mm x 1.6mm (2" x 1" x 1/16") and is made from Grade 6063 T6 aluminium. This medium-strength alloy is renowned for its high corrosion resistance and good mechanical strength. It is also heat treatable, making it suitable for a range of applications. This aluminium angle is readily suited for welding and brazing, and it offers excellent formability in manufacturing processes.
Typical Uses
Aluminium angle is commonly utilized in various applications including:
- Store fronts
- Frame building
- Automotive components and trims
- Cranes
- Trusses
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 50.8mm |
| Width | 25.4mm |
| Thickness | 1.6mm |
Technical Specifications
- Material: Grade 6063 T6 Aluminium
- Strength: Medium strength alloy
- Corrosion Resistance: High
- Heat Treatable: Yes
- Weldable: Yes
- Brazing: Compatible
- Formability: Good
FAQ
What is the maximum length of the aluminium angle?
This specific angle measures 50.8mm in length.
Can this aluminium angle be used in outdoor applications?
Yes, the high corrosion resistance makes it suitable for outdoor applications.
Is this aluminium angle easy to work with for welding?
Yes, it is readily suited for welding and brazing, ensuring ease of use in fabrication.
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 50.8 × 25.4 × 1.6 mm (2″ × 1″ × 1/16″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | 6063 |
| SKU | AWH_IS301 |
Material properties
| Width | 25.4mm |
|---|---|
| Thickness | 1.6mm |
Catalogue name Premium 50.8mm x 25.4mm x 1.6mm Aluminium Unequal Angle - Grade 6063 T6 with High Corrosion Resistance for Versatile Applications
Technical data (EN AW-6063)
Technical data · alloy
6063 / EN AW-6063
- Si 0.2–0.6%Silicon
- Mg 0.45–0.9%Magnesium
- Alloy
- Architectural aluminium alloy
- Designation
- EN AW-6063
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
50.8 × 25.4 × 1.6 mm (2″ × 1″ × 1/16″) £29.14 per 1000 mm length
