EN AW-6082 · Structural aluminium alloy
Premium 76.2mm x 50.8mm x 6.3mm Aluminium Unequal Angle - High-Strength 6082 T6 Alloy for Structural Applications
76.2 × 50.8 × 6.3 mm (3″ × 2″ × 1/4″)4000 mm length
76.2 × 50.8 × 6.3 mm
- Excellent corrosion resistance
£218.56incl. VATper 4000 mm length
Quantity 1 = one 4000 mm length.
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this aluminium angle
Product Overview
This Premium Aluminium Unequal Angle measures 76.2mm x 50.8mm x 6.3mm and is manufactured from High-Strength Grade 6082 T6 aluminium. Known for its medium strength and excellent corrosion resistance, this alloy is enhanced with magnesium, manganese, and silicon, ensuring good machinability and weldability. It is widely regarded as the highest strength grade in the 6000 series, making it an ideal choice for various structural applications.
Typical Uses
Typical applications for this aluminium angle include:
- Frame building
- Automotive components and trims
- Cranes
- Trusses
- Bridges
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length | 76.2mm |
| Width | 50.8mm |
| Thickness | 6.3mm |
Technical Specifications
- Material: Grade 6082 T6 Aluminium
- Corrosion Resistance: Very Good
- Machinability: Good
- Weldability: Good
FAQ
What is the strength of 6082 T6 aluminium?
Grade 6082 T6 aluminium is considered a medium strength alloy, widely used in structural applications due to its excellent mechanical properties.
Can this aluminium angle be welded?
Yes, the 6082 T6 aluminium alloy has good weldability, making it suitable for various welding techniques.
What are the typical applications for aluminium angles?
Aluminium angles are typically used in frame building, automotive components, cranes, trusses, and bridges.
Key features
- Grade 6082 (EN AW-6082, structural aluminium alloy)
- Excellent corrosion resistance
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 4000 mm length.
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 76.2 × 50.8 × 6.3 mm (3″ × 2″ × 1/4″) |
|---|---|
| Supplied length | 4000 mm |
| Finish | Not stated |
| Grade | 6082 |
| SKU | AWH_IS1136 |
Material properties
| Width | 50.8mm |
|---|---|
| Thickness | 6.3mm |
Catalogue name Premium 76.2mm x 50.8mm x 6.3mm Aluminium Unequal Angle - High-Strength 6082 T6 Alloy for Structural Applications
Technical data (EN AW-6082)
Technical data · alloy
6082 / EN AW-6082
- Si 0.7–1.3%Silicon
- Mg 0.6–1.2%Magnesium
- Mn 0.4–1.0%Manganese
- Alloy
- Structural aluminium alloy
- Designation
- EN AW-6082
- Density
- 2.70 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
76.2 × 50.8 × 6.3 mm (3″ × 2″ × 1/4″) £218.56 per 4000 mm length
