Premium 17mm AF Brass Hexagon Bar - CZ121 Alloy with High Hardness and Machinability for Various Applications
£146.20 incl. VAT
Overview
Overview
About this Brass stock
Product Overview
The Premium 17mm AF Brass Hexagon Bar is manufactured from the high-performance CZ121 alloy, known for its exceptional hardness and tensile strength. This alloy is further enhanced by the addition of lead, which improves the machinability significantly. The lead in the composition remains insoluble in the microstructure, allowing for soft particles that act as effective chip breakers during machining processes. The fabrication of CZ121 by hot working is also highly efficient, making it a reliable choice for a variety of applications.
Applications
The brass hexagon bar is versatile and suitable for numerous applications, including:
- Furniture components
- Architectural extrusions
- Electrical components
- Locks and hinges
- Nuts and bolts
Technical Specifications
This brass hexagon bar is designed to meet the needs of various industrial and commercial applications. Below are the key specifications:
Benefits The Premium Brass Hexagon Bar offers numerous advantages, including:
Typical uses
- Machined fittingsTurned parts, bushes and connectors.
- Decorative trimEdging, inlays and architectural details.
- Valves & plumbing partsBodies, spindles and fittings.
- Plaques & signageEngraved plates and nameplates.
Specifications
Specifications
This bar
- Alloy Grade
- CZ121
- Diameter
- 17mm AF
Technical data (CW614N)
Technical data
CZ121 / CW614N
- Cu 57–59%Copper
- Pb 2.5–3.5%Lead
- Zn BalanceZinc
- Alloy
- Free-machining brass
- Designation
- CW614N
- Density
- 8.47 g/cm³
Typical values for guidance. Confirm critical values with your engineer.
