CW614N · Free-machining brass
Premium 19mm (3/4") Brass Round Bar - CZ121 Grade with High Hardness and Excellent Machinability for Various Applications
19 mm (3/4″)1000 mm length
19 mm
- Easy to machine
£115.88incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 19 mm (3/4″).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this brass round bar
Product Overview
The Premium Brass Round Bar is manufactured from CZ121 grade, which is known for its excellent hardness and tensile strength. This alpha/beta alloy benefits from enhanced machinability due to the addition of lead in its composition. The lead particles remain insoluble in the microstructure, acting as effective chip breakers during machining processes. The fabrication of CZ121 through hot working is also highly efficient, making this brass round bar a reliable choice for various applications.
Applications
Our brass round bar is suitable for a wide range of uses, including:
- Furniture manufacturing
- Architectural extrusions
- Electrical components
- Locks and hinges
Technical Specifications
| Specification | Measurement |
|---|---|
| Diameter | 19mm (3/4") |
FAQ
What are the benefits of using CZ121 brass?
CZ121 brass offers superior hardness and tensile strength, making it ideal for applications requiring durability and reliability.
Can this brass round bar be easily machined?
Yes, the addition of lead in the alloy composition enhances its machinability, allowing for efficient machining processes.
What are the common applications for brass round bars?
Brass round bars are commonly used in furniture, architectural applications, electrical components, and various hardware items.
Key features
- Grade CZ121 (CW614N, free-machining brass)
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 19 mm (3/4″).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 19 mm (3/4″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | CZ121 |
| SKU | AWH_IS2703 |
Catalogue name Premium 19mm (3/4") Brass Round Bar - CZ121 Grade with High Hardness and Excellent Machinability for Various Applications
Technical data (CW614N)
Technical data · alloy
CZ121 / CW614N
- Cu 57–59%Copper
- Pb 2.5–3.5%Lead
- Zn BalanceZinc
- Alloy
- Free-machining brass
- Designation
- CW614N
- Density
- 8.47 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
