CW614N · Free-machining brass
Premium 25.4mm (1") Brass Round Bar - CZ121 Alpha/Beta Alloy with Enhanced Machinability and Durability
25.4 mm (1″)1000 mm length
25.4 mm
- Easy to machine
£237.56incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 25.4 mm (1″).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt; a 25% restocking fee applies. Returns policy
Overview
Overview
About this brass round bar
Product Overview
The Premium Brass Round Bar is crafted from the high-performance CZ121 grade, an alpha/beta alloy known for its exceptional hardness and tensile strength. This material features improved machinability due to the addition of lead in its composition, which remains insoluble in the microstructure. The lead particles act as chip breakers, enhancing the ease of machining.
Applications
This versatile brass round bar is suitable for various applications, including:
- Furniture manufacturing
- Architectural extrusions
- Electrical components
- Locks and hinges
Technical Specifications
Details regarding the material properties and specifications are as follows:
- Material: Brass (CZ121 Alpha/Beta Alloy)
- Diameter: 25.4mm (1 inch)
- Machinability: Enhanced due to lead addition
- Fabrication: Excellent hot workability
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Diameter | 25.4mm (1 inch) |
FAQs
-
What is CZ121 alloy?
CZ121 is a high-performance brass alloy known for its hardness, strength, and excellent machinability. -
Can this brass round bar be used for outdoor applications?
Yes, brass has good corrosion resistance and can be used in outdoor settings, although protective coatings may enhance longevity. -
How is the lead in CZ121 beneficial for machining?
The lead in CZ121 acts as a chip breaker, improving the machining process by reducing wear on tools and enhancing surface finish.
Key features
- Grade CZ121 (CW614N, free-machining brass)
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 25.4 mm (1″).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 25.4 mm (1″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | CZ121 |
| SKU | AWH_IS2706 |
Catalogue name Premium 25.4mm (1") Brass Round Bar - CZ121 Alpha/Beta Alloy with Enhanced Machinability and Durability
Technical data (CW614N)
Technical data · alloy
CZ121 / CW614N
- Cu 57–59%Copper
- Pb 2.5–3.5%Lead
- Zn BalanceZinc
- Alloy
- Free-machining brass
- Designation
- CW614N
- Density
- 8.47 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
25.4 mm (1″) £237.56 per 1000 mm length
