CW614N · Free-machining brass
Premium 38.1mm (1 1/2") Diameter Brass Round Bar - CZ121 Alloy with High Corrosion Resistance and Excellent Machinability
38.1 mm (1 1/2″)1000 mm length
38.1 mm
- High corrosion resistance
- Easy to machine
£538.80incl. VATper 1000 mm length
Quantity 1 = one 1000 mm length of 38.1 mm (1 1/2″).
Secure checkout: Card, Apple Pay, Google Pay or Shop Pay
- Availability
- Available to order
- Delivery
- UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
- Returns
- Return within 14 days of receipt. Returns policy
Overview
Overview
About this brass round bar
Product Overview
The Premium Brass Round Bar has a diameter of 38.1mm (1 1/2") and is constructed from CZ121 grade, an alpha/beta alloy. This material offers exceptional ductility and can be cold worked, making it suitable for various machining applications. The addition of lead to the alloy composition enhances its machinability, as the lead particles remain insoluble in the brass's microstructure, serving as effective chip breakers.
Brass is well-known for its high corrosion resistance and tensile strength, making it an ideal choice for numerous applications.
Applications
The following are common applications for the brass round bar:
- Furniture manufacturing
- Architectural extrusions
- Electrical components
- Locks and hinges
Technical Specifications
Here are the key specifications of the Premium Brass Round Bar:
| Specification | Measurement |
|---|---|
| Diameter | 38.1mm (1 1/2") |
| Material Grade | CZ121 |
| Corrosion Resistance | High |
| Tensile Strength | High |
Frequently Asked Questions
1. What is the main benefit of using brass for machining?
Brass is favored for machining due to its excellent machinability, corrosion resistance, and high tensile strength, making it suitable for a wide range of applications.
2. Can this brass round bar be used for outdoor applications?
Yes, the high corrosion resistance of brass allows it to be used effectively in outdoor environments.
3. Is the brass round bar suitable for electrical components?
Absolutely! Brass is commonly used in electrical components due to its good conductivity and resistance to corrosion.
Key features
- Grade CZ121 (CW614N, free-machining brass)
- High corrosion resistance
- Easy to machine
FAQs
FAQs
Before you order
What does one unit of this item supply?
Quantity 1 = one 1000 mm length of 38.1 mm (1 1/2″).
Can you supply other sizes or a cutting list?
Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.
Specifications
Specifications
Product dimensions
| Size | 38.1 mm (1 1/2″) |
|---|---|
| Supplied length | 1000 mm |
| Finish | Not stated |
| Grade | CZ121 |
| SKU | AWH_IS5980 |
Material properties
| Material Grade | CZ121 |
|---|---|
| Corrosion Resistance | High |
| Tensile Strength | High |
Catalogue name Premium 38.1mm (1 1/2") Diameter Brass Round Bar - CZ121 Alloy with High Corrosion Resistance and Excellent Machinability
Technical data (CW614N)
Technical data · alloy
CZ121 / CW614N
- Cu 57–59%Copper
- Pb 2.5–3.5%Lead
- Zn BalanceZinc
- Alloy
- Free-machining brass
- Designation
- CW614N
- Density
- 8.47 g/cm³
Typical composition for the grade, for guidance — not a mill certificate for this item.
38.1 mm (1 1/2″) £538.80 per 1000 mm length
