Product Description
This Premium EV Charging Cable allows you to charge your electric vehicle from any public or home EV charging point. Available in lengths of 5 meters and 10 meters, it is designed to suit all your charging needs.
The Type 2 end of this cable must always be plugged directly into a charge point socket. It cannot be used as an extension or an adaptor to a tethered lead.
Features
- 16/32 Amp single phase at 3.6/7.2 kW
- Type 1 (SAEJ1772) to Type 2 (IEC62196 / Mennekes)
- Available in 5/10 meter lengths
- Lightweight and ultra-flexible for easy storage and transport
- Long-lasting and reliable performance
- IEC certified for safety and reliability
- TUV certified for quality assurance
- CE compliant to European standards
- IP54 rated for dust and water resistance
- J1772 plug complete with padlock facility (padlock available separately)
- Operating voltage: 240VAC
- Tested to 2,500 VDC for durability
- Operating temperature range: -30°C to +60°C
- Hard-wearing polybutylene terephthalate (PBT) handle
- Copper alloy contacts for excellent conductivity
Technical Specifications
| Specification | Measurement |
|---|---|
| Length Options | 5m, 10m |
| Operating Voltage | 240VAC |
| Test Voltage | 2,500 VDC |
| Operating Temperature | -30°C to +60°C |
Frequently Asked Questions
-
Can I use this cable with any EV charging station?
Yes, this cable is compatible with any charging station that supports Type 2 connectors. -
Is this cable suitable for outdoor use?
Yes, it is IP54 rated, making it resistant to dust and water, suitable for outdoor environments. -
What is the maximum charging speed I can achieve?
The cable supports up to 32 Amps, allowing for rapid charging depending on the station capabilities.
