Product Overview
Our Premium EV Charging Cable is designed to meet the highest quality standards, allowing you to charge your electric vehicle from any public or home EV charging point. Available in 5 or 10 meters, this cable caters to all your charging needs.
The Type 2 end of this cable must always be plugged directly into a charge point socket; this cable cannot be used as an extension or an adapter to a tethered lead.
Features
- 16/32 amp single phase at 3.6/7.2 kW
- Type 2 to Type 2 (IEC62196 / Mennekes)
- 5/10 metre long, lightweight and ultra-flexible for easy storage and transportation
- Long-lasting and reliable performance
- IEC certified, TUV certified, and CE compliant
- IP54 rated for protection against dust and water
- Operating voltage of 240VAC
- Tested to 2,500 VDC for safety assurance
- Operating temperature range from -30°C to +60°C
- Hard-wearing polybutylene terephthalate (PBT) handle
- Copper alloy contacts for improved conductivity
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Length Options | 5m / 10m |
| Operating Voltage | 240VAC |
| Operating Temperature Range | -30°C to +60°C |
| IP Rating | IP54 |
Technical Specifications
- Certifications: IEC, TUV, CE
- Test Voltage: 2,500 VDC
- Material: Polybutylene Terephthalate (PBT) and Copper Alloy
FAQs
Q: Can this cable be used as an extension cord?
A: No, this cable must be plugged directly into a charge point socket.
Q: What is the maximum length available for this cable?
A: The cable is available in lengths of 5 meters and 10 meters.
Q: Is this cable suitable for outdoor use?
A: Yes, it is IP54 rated, providing protection against dust and splashes of water.
