EN AW-6082 · Structural aluminium alloy

Professional 9.5mm x 6.3mm Structural Grade Aluminium Flat Bar - High Strength 6082 T6 Alloy for Heavy-Duty Applications

9.5 × 6.3 mm (3/8″ × 1/4″)1000 mm length

PhotoProfessional 9.5mm x 6.3mm Structural Grade Aluminium Flat Bar - High Strength 6082 T6 Alloy for Heavy-Duty Applications 9.5 × 6.3 mm (3/8″ × 1/4″) – photo 1 of 2
PhotoProfessional 9.5mm x 6.3mm Structural Grade Aluminium Flat Bar - High Strength 6082 T6 Alloy for Heavy-Duty Applications 9.5 × 6.3 mm (3/8″ × 1/4″) – photo 2 of 2
Dimensions W 9.5 mm T 6.3 mm
  • Easy to machine

£29.86incl. VATper 1000 mm length

Quantity 1 = one 1000 mm length.

LengthSupplied as one length
Finish

Item total £29.86 1 × £29.86 per 1000 mm length

Secure checkout: Card, Apple Pay, Google Pay or Shop Pay

Availability
Available to order
Delivery
UK only. Flat £20 delivery per order. Handling 1–2 working days, then 2–4 working days in transit. Delivery information
Returns
Return within 14 days of receipt. Returns policy
Overview

Overview

About this aluminium flat bar

Product Overview

This Professional Aluminium Flat Bar measures 9.5mm x 6.3mm (3/8" x 1/4") and is made from structural grade 6082 T6 aluminium, known for its exceptional strength and versatility. This high-performance alloy is the strongest in the 6000 series and is enhanced with magnesium, manganese, and silicon, providing superior mechanical properties and corrosion resistance while maintaining excellent machinability and weldability.

Applications

The 6082 T6 aluminium flat bar is well-suited for a variety of highly stressed applications such as:

  • Trusses
  • Bridges
  • Cranes
  • Automotive components

Dimensions & Specifications

Specification Measurement
Length 9.5mm
Width 6.3mm

Technical Specifications

The following are key features of this aluminium flat bar:

  • Material: 6082 T6 Aluminium
  • High strength and durability
  • Corrosion resistant
  • Good machinability and weldability

FAQs

Q: What is the maximum load capacity of this aluminium flat bar?
A: The load capacity may vary based on the application and installation. It is advisable to consult an engineering professional for specific load requirements.

Q: Can this aluminium flat bar be welded?
A: Yes, the 6082 T6 aluminium flat bar has excellent weldability, making it suitable for various fabrication processes.

Q: Is this bar suitable for outdoor applications?
A: Yes, the corrosion-resistant properties of the 6082 T6 alloy make it suitable for outdoor use.

Key features

  • Grade 6082 (EN AW-6082, structural aluminium alloy)
  • Easy to machine
FAQs

FAQs

Before you order

What does one unit of this item supply?

Quantity 1 = one 1000 mm length.

Can you supply other sizes or a cutting list?

Yes — send the sizes and lengths you need with Request a quote, or call 01744 520110.

Specifications

Specifications

Product dimensions

Dimensions and supply details for this aluminium flat bar
Size9.5 × 6.3 mm (3/8″ × 1/4″)
Supplied length1000 mm
FinishNot stated
Grade6082
SKUAWH_IS6566

Material properties

Material properties
Width6.3mm

Catalogue name Professional 9.5mm x 6.3mm Structural Grade Aluminium Flat Bar - High Strength 6082 T6 Alloy for Heavy-Duty Applications

Technical data (EN AW-6082)

Technical data · alloy

6082 / EN AW-6082

  • Si 0.7–1.3%Silicon
  • Mg 0.6–1.2%Magnesium
  • Mn 0.4–1.0%Manganese
Alloy
Structural aluminium alloy
Designation
EN AW-6082
Density
2.70 g/cm³

Typical composition for the grade, for guidance — not a mill certificate for this item.
